جديد اللودر بعجل MAXUS Loader Model: 128 cm

MAXUS Loader

Model: 128 cm

Machine Parameters:

Minimum turning radius (mm): 4250

Body length (mm): 5150

Theoretical lifting angle (°): 18

Vehicle width (mm): 1280

Maximum speed (km/h): 9.7

Height (mm): 1850

Minimum speed (km/h): 4

Minimum ground clearance (mm): 180

Maximum unloading height (mm): 1200

Wheelbase (mm): 980

Lifting time (empty) (s): ≤2.1

Nominal load capacity (kg): 1600

Falling time (empty) (s): ≤2

Total weight (kg): 5500

Unloading time (empty) (s): ≤1.2

Bucket (length * width * height) (mm): 12401070530

Triple sum time (s): ≤6.3

Bucket capacity (m³): 0.6

Axle distance (mm): 2300

Maximum lifting force (kN): 55

Unloading distance (mm): 825

Maximum traction force (kN): 48

Discharge angle (°): 35.1

Operating condition of the connector:

Traction force (kN): 51

Engine and Drive System:

Engine brand: YUNNEI, type 280, high and low speeds

Rated power (kW): 65 kW

Gear shift lever: Forward 2, Reverse 2

Rated speed (r/min): 2400

Braking system: Pneumatic brake

Number of cylinders: 4

Axle brake: Disc brake

Tire model: 255/70D406

Front wheel air pressure (MPa): 0.33

Rear wheel air pressure (MPa): 0.3

Fuel and Hydraulic System:

Control type: Full hydraulic control

Fuel capacity (L): 65.5

Steering angle (degrees): 32.5

Hydraulic oil capacity (L): 65.5

Working pressure of the system (MPa): 16

Single axle capacity (L): 14

Engine oil capacity (L): 6.5

Transmission oil capacity (L): 24

Brake system oil capacity (L): 3
