جديد خلاطه اسمنت Constmach Planeten-Betonmischer (Paddelmischer)

You can call us 24/7 for planetary type concrete mixer for sale.

The planetary type concrete mixer series of Constmach brand reveals its difference in the sector by offering suitable solutions for projects of all sizes. The CPLN series is offered in a wide range from 0.5 to 2 with various loading capacities and is designed to meet all kinds of needs of users. These mixers are equipped with high-quality motor options and durable materials, so they provide impressive performance even in long-term and demanding use.

Each model offers maximum durability with specially designed Hardox 450 side wear plates and ST 52 bottom wear plates. In addition, the Ni-Hard mixing handle wear plates, ranging from 25mm to 30mm, show excellent resistance even under continuous operating conditions. The CPLN series has been developed to provide excellent blend and durability even in harsh conditions.

User-friendly features such as hydraulic discharge cover and maintenance cover with safety sensor increase work safety and ease of use. These features make maintenance processes easier while maximizing operational efficiency. Constmach's planetary type concrete mixer series takes the industry standards to a new level in terms of durability, efficiency and user safety.

The CPLN series combines technology and innovation in its field to provide reliable and efficient performance in all your projects.Dec. These mixers, each of which is carefully designed, contribute to the success of your projects by providing ideal solutions for your long-term investments.

Technical Specifications of CPLN - 0.5 Model Planetary Type Concrete Mixer

Loading Volume: 750 lt

Fresh Concrete Volume: 625 lt

Compacted Concrete Volume: 500 lt

Engine Power: 15.5 kW

Side Body Wear Plates: 10 mm Hardox 450

Bottom Wear Plates: 10 mm ST 52

Mixing Handle Wear Plates: 25 mm Ni-Hard

Hydraulic Discharge Cover: Available

Maintenance Cover with Safety Sensor: Available

CPLN - 0.75 Model Planetary Type Concrete Mixer Technical Specifications

Loading Volume: 1.000 lt

Fresh Concrete Volume: 875 lt

Compacted Concrete Volume: 750 lt

Motor Power: 30 kW

Side Body Wear Plates: 10 mm Hardox 450

Bottom Wear Plates: 10 mm ST 52

Mixing Handle Wear Plates: 25 mm Ni-Hard

Hydraulic Discharge Cover: Available

Maintenance Cover with Safety Sensor: Available

Technical Specifications of CPLN - 1 Model Planetary Type Concrete Mixer

Loading Volume: 1.500 lt

Fresh Concrete Volume: 1.250 lt

Compacted Concrete Volume: 1.000 lt

Engine Power: 45 kW

Side Body Wear Plates: 15 mm Hardox 450

Bottom Wear Plates: 10 mm ST 52

Mixing Handle Wear Plates: 25 mm Ni-Hard

Hydraulic Discharge Cover: Available

Maintenance Cover with Safety Sensor: Available

Technical Specifications of CPLN - 1.5 Model Planetary Type Concrete Mixer

Loading Volume: 2.250 lt

Fresh Concrete Volume: 2.000 lt

Compacted Concrete Volume: 1.500 lt

Engine Power: 2 x 30 kW

Side Body Wear Plates: 10 mm Hardox 450

Bottom Wear Plates: 10 mm ST 52

Mixing Handle Wear Plates: 25 mm Ni-Hard

Hydraulic Discharge Cover: Available

Maintenance Cover with Safety Sensor: Available

Technical Specifications of CPLN - 2 Model Planetary Type Concrete Mixer

Loading Volume: 3,000 lt

Fresh Concrete Volume: 2.500 lt

Compacted Concrete Volume: 2.000 lt

Engine Power: 2 x 37 kW

Side Body Wear Plates: 15 mm Hardox 450

Bottom Wear Plates: 12 mm ST 52

Mixing Handle Wear Plates: 30 mm Ni-Hard

Hydraulic Discharge Cover: Available

Maintenance Cover with Safety Sensor: Available
