جديد خزان الأسمنت Constmach 2000 Ton Capacity Cement Silo

you can call 24/7 for the 2000 ton cement silo.

CS-2000 model cement silo is designed to add strength to your project with its high capacity and superior construction features. this silo, which is produced to meet your large volume storage needs with a capacity of 2000 tons, stands out with its durability and safety.

The CS-2000 provides effective use in a wide area with a height of 20.758 mm and a width of Ø 12.400 mm. The silo has a solid structure with a weight of 95,000 kg and is supported by a base number of 16. The soles of the feet are made of 20-25 mm metal plate, the tapered part is made of 10 mm metal plate, the main body is made of ISE 10-8-6 mm sheet metal. The upper cover strip is made of 6 mm sheet metal, the foot bars are manufactured as NPL 80 mm steel profile.

The silo has guard rails for the outer deck ladder starting from the base and ending at the upper hatch and around the upper hatch. the 4" filling tube is expandable to the sole foot and provides ease of use. In addition, all the necessary statistics for the silos have been calculated and displayed to the approved designs.

CS-2000 provides a strong protection, painted with one coat of anticorrosive paint and two coats of epoxy paint, the total paint quality is 140 microns. These features guarantee that the silo is long-lasting and permanent.

This high quality silo is an excellent option to meet the needs of your projects. With the CS-2000, the size offers a reliable solution. Buy now and add value to your project.

Technical Specifications of CS-2000 - 2000 Ton Cement Silo

Silo Capacity 2.000 tons​

Silo Height 20.758mm

Silo Width Ø 12.400mm

Basic Number 16

Silo Outlet Ø 400 mm

Silo Weight 95.000kg

The Soles of the feet are made of 20-25 mm metal sheet

10 mm sheet metal is produced from the Conical Part

10-8-6 mm sheet metal is Produced from the Main Body

The Top Cover is made of 6 mm sheet metal with Strip

The Foot Bars are manufactured as NPL 80mm steel profile

The silo includes an external deck ladder starting from the floor and ending at the upper hatch

There are Protection Rails Around the Top Cover of the Silo

The Filled Pipe has an extendable extension to the 4" up base foot

All the Necessary Statistics for Silos are Displayed to the Calculated and Approved Designs

Painting 1 layer of anticorrosive paint, 2 layers of top coat epoxy paint, total paint thickness 140 microns
